ISO 9001:2015 Certified Manufacturer

World-Class
Jigs &
Fixtures

AC Private Limited engineers precision jigs, fixtures, and tooling solutions that power manufacturing excellence across industries — from automotive to aerospace.

View Catalog Talk to Us
600+
Products in Catalog
22+
Years Experience
300+
Satisfied Clients
±5μm
Precision Tolerance
Industrial jig
Quality Assured Every product CMM verified
CNC fixture
Welding fixture
Drilling Jigs ✦ Welding Fixtures ✦ Assembly Fixtures ✦ CNC Machining Fixtures ✦ Inspection Fixtures ✦ Modular Tooling ✦ Custom Jigs ✦ Turning Fixtures ✦ Drilling Jigs ✦ Welding Fixtures ✦ Assembly Fixtures ✦ CNC Machining Fixtures ✦ Inspection Fixtures ✦ Modular Tooling ✦ Custom Jigs ✦ Turning Fixtures ✦
ISO Certified Quality

Compliant with ISO 9001:2015. Every unit leaves our facility inspection-certified.

Micron Precision

Tolerances as tight as ±0.005 mm achieved through advanced CNC and CMM systems.

Full Catalog Online

Browse 600+ standard products or submit a custom requirement directly online.

On-Time Delivery

Streamlined workflows and dedicated logistics ensure 98.6% on-time delivery rate.

Product Lines

What We Make

Six specialized product lines engineered to handle every stage of your manufacturing workflow with precision and reliability.

01

Drilling Jigs

Multi-hole and single-hole drilling jigs with hardened guide bushings for consistent, accurate hole patterns.

Explore
02

Welding Fixtures

Robust fixtures ensuring perfect part alignment during MIG, TIG and spot welding operations with anti-spatter protection.

Explore
03

Assembly Fixtures

Custom ergonomic fixtures for sub-assembly lines featuring poka-yoke sensors and pneumatic clamping.

Explore
04

Machining Fixtures

High-rigidity CNC milling and turning fixtures with zero-point mounting for high-mix, low-volume production.

Explore
05

Inspection Fixtures

CMM-compatible inspection fixtures with kinematic locating elements for dimensional measurement without distortion.

Explore
06

Custom Tooling

Fully bespoke special-purpose jigs and fixtures engineered to your drawings with full DFM analysis and prototyping.

Explore
Our Products

Product Catalog

Click any product card for full specifications, tolerances, and material details.

Drilling Jig Pro-X Jig
ACL-JIG-2201

Drilling Jig Pro-X 200

Multi-hole precision drilling jig with hardened guide bushings and quick-release toggle clamping system.

±0.010 mm EN31 Steel
Welding Fixture HD Fixture
ACL-FIX-5501

Welding Fixture HD-550

Heavy-duty welding fixture with V-block supports, toggle clamps, and anti-spatter treated surfaces.

150 kg MS + EN8
CNC Machining Fixture Fixture
ACL-FIX-3301

CNC Milling Fixture MF-330

Zero-point mounting machining fixture with pneumatic clamping for high-mix production environments.

±0.005 mm Pneumatic
Box Jig Jig
ACL-JIG-1101

Box Jig BJ-110

Enclosed box jig for all-face drilling and boring with chip clearance channels and indexable feet.

±0.012 mm Cast Iron
Assembly Fixture Custom
ACL-CUS-4401

Assembly Fixture AF-440

Automotive sub-assembly fixture with poka-yoke error-proofing, sensor feedback and PLC integration.

Poka-Yoke PLC Ready
Inspection Fixture Fixture
ACL-FIX-2501

Inspection Fixture IF-250

Granite-based CMM inspection fixture with kinematic locating and spring-loaded non-distorting clamps.

±0.003 mm CMM Ready
Plate Jig Jig
ACL-JIG-1501

Plate Jig PL-150

Flat plate jig for simple drilling operations with reversible locating pins and adjustable fence.

±0.015 mm Mild Steel
Special Tooling Custom
ACL-CUS-6601

Special Purpose Tooling ST-660

Bespoke machining tooling designed to customer drawing with full DFM analysis and prototype validation.

DFM + FEA PPAP
How We Work

Our Process

From first enquiry to delivery, we follow a rigorous 4-step process that ensures precision at every stage.

01

Enquiry & Review

Submit your requirement. Our engineers review drawings, tolerances, and production volumes within 24 hours.

02

Design & DFM

3D modelling, DFM analysis, and FEA review to optimise your jig or fixture for performance and cost.

03

Manufacture

CNC machining, grinding, and fitting on calibrated machines. In-process inspection at every stage.

04

Inspect & Deliver

CMM final inspection with full dimensional report. Packed securely and dispatched on committed date.

Have a custom requirement?
Let's engineer it together.

Send us your drawing or describe your need — our team responds within one business day.

Request a Quote Browse Catalog
Contact Us

Get in Touch or
Request a Quote

Whether you need a standard product from our catalog or a fully custom solution, our engineering team is here to help.

Address Industrial Zone, MIDC, Maharashtra, India
Phone +91 98765 43210
Email enquiry@acprivatelimited.com
Send an Enquiry
